                                        CN












































































    NPDL-C00211011









                This AC current transmitter converts the 0 ~ 1 A AC signals to current signals. It needs an independent power supply. The input, output, and power supply are galvanically isolated from each other.








    Input signal











    Output signal











    Power Supply Mode
















                Share


















    NPDL-C00211011


















    Supply







                          Power supply
                          18 ~ 32 V DC









    Input







                          Input signal
                          0 ~ 1 A AC





                          Frequency range
                          40 Hz ~ 400 Hz





                          Overload capacity
                          double input nominal value









    Output







                          Output signal
                          4 ~ 20 mA





                          Load resistance
                          RL ≤ 550 Ω









    Transfer characterisics







                          Accuracy
                          0.2 %F.S.（0 ~ 120%）





                          Temperature drift
                          50 ppm/℃









    General parameters







                          Response time
                          ＜ 330 ms





                          Power dissipation
                          ＜ 1W









    EMC data







                          Electromagnetic compatibility
                          IEC 61326-3-1





                          Dielectric strength
                          ≥ 1500V AC (Input /Output/Power supply)





                          Insulation resistance
                          ≥ 100 MΩ (Input /Output/Power supply)









    Operating conditions







                          Operation temperature
                          -20 ℃ ~ +60 ℃





                          Storage temperature
                          -40 ℃ ~ +80 ℃









    Mechanical specifications







                          Connection method
                          Screw connection





                          Dimension
                          17.8mm (W) × 110mm (H) × 117mm (D)





                          Mounting type
                          DIN35 mm









    Certified data







                          Product approvals
                          CE, FCC
